7 Settings
(continued)
7-26
C232-302-401/402/403/404-603 / C232/EN M/A23
External devices 01 to 10
DEV01: Function group DEV01
210 047
DEV02: Function group DEV02
210 097
DEV03: Function group DEV03
210 147
DEV04: Function group DEV04
210 197
DEV05: Function group DEV05
210 247
DEV06: Function group DEV06
211 047
DEV07: Function group DEV07
211 097
DEV08: Function group DEV08
211 147
DEV09: Function group DEV09
211 197
DEV10: Function group DEV10
211 247
Canceling function groups DEV01 to DEV10 or including them in the
configuration. If the function group is cancelled from the configuration, then
all associated settings and signals are hidden, with the exception of this
setting.
DEV01: Funct. type, signal
210 034
DEV02: Funct. type, signal
210 084
DEV03: Funct. type, signal
210 134
DEV04: Funct. type, signal
210 184
DEV05: Funct. type, signal
210 234
DEV06: Funct. type, signal
211 034
DEV07: Funct. type, signal
211 084
DEV08: Funct. type, signal
211 134
DEV09: Funct. type, signal
211 184
DEV10: Funct. type, signal
211 234
Setting for the function type of the signal.
Note:
If the IEC 870-5-101 communication protocol has been set, then the ‘low
address’ of the information object will be defined by this setting. If the ILS-C
protocol has been set, then this setting will correspond to DN2.
DEV01: Inform. No., signal
210 035
DEV02: Inform. No., signal
210 085
DEV03: Inform. No., signal
210 135
DEV04: Inform. No., signal
210 185
DEV05: Inform. No., signal
210 235
DEV06: Inform. No., signal
211 035
DEV07: Inform. No., signal
211 085
DEV08: Inform. No., signal
211 135
DEV09: Inform. No., signal
211 185
DEV10: Inform. No., signal
211 235
Setting for the information number of the signal.
Note:
If the IEC 870-5-101 communication protocol has been set, then the ‘high’
address’ of the information object will be defined by this setting. If the ILS-C
protocol has been set, then this setting will correspond to DN3.
