7 Settings
(continued)
C232-302-401/402/403/404-603 / C232/EN M/A23 7-35
LIMIT: tI>
014 031
Fig. 3-93
Setting for the operate delay of the first overcurrent stage of limit value
monitoring.
LIMIT: tI>>
014 032
Fig. 3-93
Setting for the operate delay of the second overcurrent stage of limit value
monitoring.
LIMIT: I<
014 021
Fig. 3-93
Setting for the operate value of the first undercurrent stage of limit value
monitoring.
LIMIT: I<<
014 022
Fig. 3-93
Setting for the operate value of the second undercurrent stage of limit value
monitoring.
LIMIT: tI<
014 033
Fig. 3-93
Setting for the operate delay of the first undercurrent stage of limit value
monitoring.
LIMIT: tI<<
014 034
Fig. 3-93
Setting for the operate delay of the second undercurrent stage of limit value
monitoring.
LIMIT: VPG>
014 023
Fig. 3-94
Setting for the operate value of overvoltage stage VPG> of limit value
monitoring.
LIMIT: VPG>>
014 024
Fig. 3-94
Setting for the operate value of overvoltage stage VPG>> of limit value
monitoring.
LIMIT: tVPG>
014 035
Fig. 3-94
Setting for the operate delay of overvoltage stage VPG> of limit value
monitoring.
LIMIT: tVPG>>
014 036
Fig. 3-94
Setting for the operate delay of overvoltage stage VPG>> of limit value
monitoring.
LIMIT: VPG<
014 025
Fig. 3-94
Setting for the operate value of undervoltage stage VPG< of limit value
monitoring.
LIMIT: VPG<<
014 026
Fig. 3-94
Setting for the operate value of undervoltage stage VPG<< of limit value
monitoring.
LIMIT: tVPG<
014 037
Fig. 3-94
Setting for the operate delay of undervoltage stage VPG< of limit value
monitoring.
LIMIT: tVPG<<
014 038
Fig. 3-94
Setting for the operate delay of undervoltage stage VPG<< of limit value
monitoring.
LIMIT: VPP>
014 027
Fig. 3-94
Setting for the operate value of overvoltage stage VPP> of limit value
monitoring.
