Areva MiCOM C232 - Page 128

7 Settings
(continued)
7-36
C232-302-401/402/403/404-603 / C232/EN M/A23
LIMIT: VPP>>
014 028
Fig. 3-94
Setting for the operate value of overvoltage stage VPP>> of limit value
monitoring.
LIMIT: tVPP>
014 039
Fig. 3-94
Setting for the operate delay of overvoltage stage VPP> of limit value
monitoring.
LIMIT: tVPP>>
014 040
Fig. 3-94
Setting for the operate delay of overvoltage stage VPP>> of limit value
monitoring.
LIMIT: VPP<
014 029
Fig. 3-94
Setting for the operate value of undervoltage stage VPP< of limit value
monitoring.
LIMIT: VPP<<
014 030
Fig. 3-94
Setting for the operate value of undervoltage stage VPP<< of limit value
monitoring.
LIMIT: tVPP<
014 041
Fig. 3-94
Setting for the operate delay of undervoltage stage VPP< of limit value
monitoring.
LIMIT: tVPP<<
014 042
Fig. 3-94
Setting for the operate delay of undervoltage stage VPP<< of limit value
monitoring.
LIMIT: VNG>
014 043
Fig. 3-95
Setting for the operate value of overvoltage stage VNG> of limit value
monitoring.
LIMIT: VNG>>
014 044
Fig. 3-95
Setting for the operate value of overvoltage stage VNG>> of limit value
monitoring.
LIMIT: tVNG>
014 045
Fig. 3-95
Setting for the operate delay of overvoltage stage VNG> of limit value
monitoring.
LIMIT: tVNG>>
014 046
Fig. 3-95
Setting for the operate delay of overvoltage stage VNG>> of limit value
monitoring.
LIMIT: IDC,lin>
014 110
Fig. 3-96
Setting for operate value IDC,lin> for monitoring the linearized direct
current.
LIMIT: IDC,lin>>
014 111
Fig. 3-96
Setting for operate value IDC,lin>> for monitoring the linearized direct
current.
LIMIT: tIDC,lin>
014 112
Fig. 3-96
Setting for the operate delay of overcurrent stage IDC,lin>.
LIMIT: tIDC,lin>>
014 113
Fig. 3-96
Setting for the operate delay of overcurrent stage IDC,lin>>.
LIMIT: IDC,lin<
014 114
Fig. 3-96
Setting for operate value IDC,lin< for monitoring the linearized direct
current.
