7 Settings
(continued)
C232-302-401/402/403/404-603 / C232/EN M/A23 7-37
LIMIT: IDC,lin<<
014 115
Fig. 3-96
Setting for operate value IDC,lin<< for monitoring the linearized direct
current.
LIMIT: tIDC,lin<
014 116
Fig. 3-96
Setting for the operate delay of undercurrent stage IDC,lin<.
LIMIT: tIDC,lin<<
014 117
Fig. 3-96
Setting for the operate delay of undercurrent stage IDC,lin<<.
Logic
LOGIC: General enable USER
031 099
Fig. 3-98
Disabling or enabling the logic function.
LOGIC: Set 1 USER
034 030
Fig. 3-97
LOGIC: Set 2 USER
034 031
LOGIC: Set 3 USER
034 032
LOGIC: Set 4 USER
034 033
LOGIC: Set 5 USER
034 034
LOGIC: Set 6 USER
034 035
LOGIC: Set 7 USER
034 036
LOGIC: Set 8 USER
034 037
These settings define the static input conditions for the logic function.
LOGIC: Fct.assignm. outp. 1
030 000
Fig. 3-98
LOGIC: Fct.assignm. outp. 2
030 004
LOGIC: Fct.assignm. outp. 3
030 008
LOGIC: Fct.assignm. outp. 4
030 012
LOGIC: Fct.assignm. outp. 5
030 016
LOGIC: Fct.assignm. outp. 6
030 020
LOGIC: Fct.assignm. outp. 7
030 024
LOGIC: Fct.assignm. outp. 8
030 028
LOGIC: Fct.assignm. outp. 9
030 032
LOGIC: Fct.assignm. outp.10
030 036
LOGIC: Fct.assignm. outp.11
030 040
LOGIC: Fct.assignm. outp.12
030 044
LOGIC: Fct.assignm. outp.13
030 048
LOGIC: Fct.assignm. outp.14
030 052
LOGIC: Fct.assignm. outp.15
030 056
LOGIC: Fct.assignm. outp.16
030 060
LOGIC: Fct.assignm. outp.17
030 064
LOGIC: Fct.assignm. outp.18
030 068
LOGIC: Fct.assignm. outp.19
030 072
LOGIC: Fct.assignm. outp.20
030 076
LOGIC: Fct.assignm. outp.21
030 080
LOGIC: Fct.assignm. outp.22
030 084
LOGIC: Fct.assignm. outp.23
030 088
LOGIC: Fct.assignm. outp.24
030 092
LOGIC: Fct.assignm. outp.25
030 096
LOGIC: Fct.assignm. outp.26
031 000
LOGIC: Fct.assignm. outp.27
031 004
LOGIC: Fct.assignm. outp.28
031 008
LOGIC: Fct.assignm. outp.29
031 012
