7 Settings
(continued)
7-38
C232-302-401/402/403/404-603 / C232/EN M/A23
LOGIC: Fct.assignm. outp.30
031 016
LOGIC: Fct.assignm. outp.31
031 020
LOGIC: Fct.assignm. outp.32
031 024
These settings assign functions to the outputs.
LOGIC: Op. mode t output 1
030 001
Fig. 3-98
LOGIC: Op. mode t output 2
030 005
LOGIC: Op. mode t output 3
030 009
LOGIC: Op. mode t output 4
030 013
LOGIC: Op. mode t output 5
030 017
LOGIC: Op. mode t output 6
030 021
LOGIC: Op. mode t output 7
030 025
LOGIC: Op. mode t output 8
030 029
LOGIC: Op. mode t output 9
030 033
LOGIC: Op. mode t output 10
030 037
LOGIC: Op. mode t output 11
030 041
LOGIC: Op. mode t output 12
030 045
LOGIC: Op. mode t output 13
030 049
LOGIC: Op. mode t output 14
030 053
LOGIC: Op. mode t output 15
030 057
LOGIC: Op. mode t output 16
030 061
LOGIC: Op. mode t output 17
030 065
LOGIC: Op. mode t output 18
030 069
LOGIC: Op. mode t output 19
030 073
LOGIC: Op. mode t output 20
030 077
LOGIC: Op. mode t output 21
030 081
LOGIC: Op. mode t output 22
030 085
LOGIC: Op. mode t output 23
030 089
LOGIC: Op. mode t output 24
030 093
LOGIC: Op. mode t output 25
030 097
LOGIC: Op. mode t output 26
031 001
LOGIC: Op. mode t output 27
031 005
LOGIC: Op. mode t output 28
031 009
LOGIC: Op. mode t output 29
031 013
LOGIC: Op. mode t output 30
031 017
LOGIC: Op. mode t output 31
031 021
LOGIC: Op. mode t output 32
031 025
These settings define the operating modes for the output timer stages.
