7 Settings
(continued)
C232-302-401/402/403/404-603 / C232/EN M/A23 7-51
External devices 01 t o10
DEV01: Designat. ext. dev.
210 000
Fig. 3-2
DEV02: Designat. ext. dev.
210 050
DEV03: Designat. ext. dev.
210 100
DEV04: Designat. ext. dev.
210 150
DEV05: Designat. ext. dev.
210 200
DEV06: Designat. ext. dev.
211 000
DEV07: Designat. ext. dev.
211 050
DEV08: Designat. ext. dev.
211 100
DEV09: Designat. ext. dev.
211 150
DEV10: Designat. ext. dev.
211 200
Setting for the designation of the respective external device.
Note:
This setting is only active if the external device designations are displayed
on the Bay Panel.
DEV01: Op.time switch. dev.
210 004
Fig. 3-105,
3-111
DEV02: Op.time switch. dev.
210 054
DEV03: Op.time switch. dev.
210 104
DEV04: Op.time switch. dev.
210 154
DEV05: Op.time switch. dev.
210 204
DEV06: Op.time switch. dev.
211 004
DEV07: Op.time switch. dev.
211 054
DEV08: Op.time switch. dev.
211 104
DEV09: Op.time switch. dev.
211 154
DEV10: Op.time switch. dev.
211 204
Setting for the operating time of the switchgear unit (switching device).
DEV01: Latching time
210 005
Fig. 3-106
DEV02: Latching time
210 055
DEV03: Latching time
210 105
DEV04: Latching time
210 155
DEV05: Latching time
210 205
DEV06: Latching time
211 005
DEV07: Latching time
211 055
DEV08: Latching time
211 105
DEV09: Latching time
211 155
DEV10: Latching time
211 205
Setting for the time that a control command persists after a switchgear
position signal – Open or Closed – has been received.
DEV01: Gr. assign. debounc.
210 011
Fig. 3-105,
3-111
DEV02: Gr. assign. debounc.
210 061
DEV03: Gr. assign. debounc.
210 111
DEV04: Gr. assign. debounc.
210 161
DEV05: Gr. assign. debounc.
210 211
DEV06: Gr. assign. debounc.
211 011
DEV07: Gr. assign. debounc.
211 061
DEV08: Gr. assign. debounc.
211 111
DEV09: Gr. assign. debounc.
211 161
DEV10: Gr. assign. debounc.
211 211
Assign the external device to one of eight groups for debouncing and
chatter suppression.
