7 Settings
(continued)
7-52
C232-302-401/402/403/404-603 / C232/EN M/A23
DEV01: Interm. pos. suppr.
210 012
Fig. 3-105,
3-111
DEV02: Interm. pos. suppr.
210 062
DEV03: Interm. pos. suppr.
210 112
DEV04: Interm. pos. suppr.
210 162
DEV05: Interm. pos. suppr.
210 212
DEV06: Interm. pos. suppr.
211 012
DEV07: Interm. pos. suppr.
211 062
DEV08: Interm. pos. suppr.
211 112
DEV09: Interm. pos. suppr.
211 162
DEV10: Interm. pos. suppr.
211 212
This setting determines whether the ‘intermediate position’ signal will be
suppressed or not while the switchgear unit is operating.
DEV01: Stat.ind.interm.pos.
210 027
Fig. 3-105,
3-111
DEV02: Stat.ind.interm.pos.
210 077
DEV03: Stat.ind.interm.pos.
210 127
DEV04: Stat.ind.interm.pos.
210 177
DEV05: Stat.ind.interm.pos.
210 227
DEV06: Stat.ind.interm.pos.
211 027
DEV07: Stat.ind.interm.pos.
211 077
DEV08: Stat.ind.interm.pos.
211 127
DEV09: Stat.ind.interm.pos.
211 177
DEV10: Stat.ind.interm.pos.
211 227
This setting determines whether the actual status will be signaled with a 5 s
delay after the ‘Faulty position’ signal is issued.
DEV01: Oper. mode cmd.
210 024
Fig. 3-110
DEV02: Oper. mode cmd.
210 074
DEV03: Oper. mode cmd.
210 124
DEV04: Oper. mode cmd.
210 174
DEV05: Oper. mode cmd.
210 224
DEV06: Oper. mode cmd.
211 024
DEV07: Oper. mode cmd.
211 074
DEV08: Oper. mode cmd.
211 124
DEV09: Oper. mode cmd.
211 174
DEV10: Oper. mode cmd.
211 224
Select from long command, short command or time control for the operating
mode of the command.
DEV01: Inp.asg. sw.tr. plug
210 014
Fig. 3-105,
3-111
DEV02: Inp.asg. sw.tr. plug
210 064
DEV03: Inp.asg. sw.tr. plug
210 114
DEV04: Inp.asg. sw.tr. plug
210 164
DEV05: Inp.asg. sw.tr. plug
210 214
DEV06: Inp.asg. sw.tr. plug
211 014
DEV07: Inp.asg. sw.tr. plug
211 064
DEV08: Inp.asg. sw.tr. plug
211 114
DEV09: Inp.asg. sw.tr. plug
211 164
DEV10: Inp.asg. sw.tr. plug
211 214
Definition of the binary signal used to signal the position (plugged-in /
unplugged) of the switch truck plug.
