Areva MiCOM C232 - Page 146

7 Settings
(continued)
7-54
C232-302-401/402/403/404-603 / C232/EN M/A23
DEV01: Inp.asg.el.ctrl.open
210 019
Fig. 3-106
DEV02: Inp.asg.el.ctrl.open
210 069
DEV03: Inp.asg.el.ctrl.open
210 119
DEV04: Inp.asg.el.ctrl.open
210 169
DEV05: Inp.asg.el.ctrl.open
210 219
DEV06: Inp.asg.el.ctrl.open
211 019
DEV07: Inp.asg.el.ctrl.open
211 069
DEV08: Inp.asg.el.ctrl.open
211 119
DEV09: Inp.asg.el.ctrl.open
211 169
DEV10: Inp.asg.el.ctrl.open
211 219
This setting defines the binary signal that will be used as the control signal
to move the switchgear unit to the open position.
Note:
Only signals that are defined in the DEVxx function groups can be selected.
DEV01: Inp.asg.el.ctr.close
210 020
Fig. 3-106
DEV02: Inp.asg.el.ctr.close
210 070
DEV03: Inp.asg.el.ctr.close
210 120
DEV04: Inp.asg.el.ctr.close
210 170
DEV05: Inp.asg.el.ctr.close
210 220
DEV06: Inp.asg.el.ctr.close
211 020
DEV07: Inp.asg.el.ctr.close
211 070
DEV08: Inp.asg.el.ctr.close
211 120
DEV09: Inp.asg.el.ctr.close
211 170
DEV10: Inp.asg.el.ctr.close
211 220
This setting defines the binary signal that will be used as the control signal
to move the switchgear unit to the closed position.
Note:
Only signals that are defined in the DEVxx function groups can be selected.
DEV01: Inp. asg. end Open
210 015
Fig. 3-112
DEV02: Inp. asg. end Open
210 065
DEV03: Inp. asg. end Open
210 115
DEV04: Inp. asg. end Open
210 165
DEV05: Inp. asg. end Open
210 215
DEV06: Inp. asg. end Open
211 015
DEV07: Inp. asg. end Open
211 065
DEV08: Inp. asg. end Open
211 115
DEV09: Inp. asg. end Open
211 165
DEV10: Inp. asg. end Open
211 215
This setting defines the binary signal that will be used to terminate the
'Open' command.
Note:
This setting is only visible (active) for bay types that are defined for 'direct
motor control'.
