7 Settings
(continued)
C232-302-401/402/403/404-603 / C232/EN M/A23 7-55
DEV01: Inp. asg. end Close
210 016
Fig. 3-112
DEV02: Inp. asg. end Close
210 066
DEV03: Inp. asg. end Close
210 116
DEV04: Inp. asg. end Close
210 166
DEV05: Inp. asg. end Close
210 216
DEV06: Inp. asg. end Close
211 016
DEV07: Inp. asg. end Close
211 066
DEV08: Inp. asg. end Close
211 116
DEV09: Inp. asg. end Close
211 166
DEV10: Inp. asg. end Close
211 216
This setting defines the binary signal that will be used to terminate the
'Close' command.
Note:
This setting is only visible (active) for bay types that are defined for 'direct
motor control'.
DEV01: Open w/o stat.interl
210 025
Fig. 3-108
DEV02: Open w/o stat.interl
210 075
DEV03: Open w/o stat.interl
210 125
DEV04: Open w/o stat.interl
210 175
DEV05: Open w/o stat.interl
210 225
DEV06: Open w/o stat.interl
211 025
DEV07: Open w/o stat.interl
211 075
DEV08: Open w/o stat.interl
211 125
DEV09: Open w/o stat.interl
211 175
DEV10: Open w/o stat.interl
211 225
This setting specifies whether switching to open position is permitted without
a check by the station interlock function.
DEV01: Close w/o stat. int.
210 026
Fig. 3-108
DEV02: Close w/o stat. int.
210 076
DEV03: Close w/o stat. int.
210 126
DEV04: Close w/o stat. int.
210 176
DEV05: Close w/o stat. int.
210 226
DEV06: Close w/o stat. int.
211 026
DEV07: Close w/o stat. int.
211 076
DEV08: Close w/o stat. int.
211 126
DEV09: Close w/o stat. int.
211 176
DEV10: Close w/o stat. int.
211 226
This setting specifies whether switching to closed position is permitted
without a check by the station interlock function.
