DEV01: Fct.asg.BI w/o SI op
210 041
Fig. 3-107
DEV02: Fct.asg.BI w/o SI op
210 091
DEV03: Fct.asg.BI w/o SI op
210 141
DEV04: Fct.asg.BI w/o SI op
210 191
DEV05: Fct.asg.BI w/o SI op
210 241
DEV06: Fct.asg.BI w/o SI op
211 041
DEV07: Fct.asg.BI w/o SI op
211 091
DEV08: Fct.asg.BI w/o SI op
211 141
DEV09: Fct.asg.BI w/o SI op
211 191
DEV10: Fct.asg.BI w/o SI op
211 241
This setting defines which output will issue the 'Open' enable to the
interlocking logic when there is 'bay interlock without substation interlock'.
Note:
The interlock conditions for bay interlock without station interlock are
included in the bay type definitions (see List of Bay Types in the Appendix).
If the interlock condition is to be modified, this is possible by modifying the
corresponding Boolean equation in the interlocking logic or by defining a
new interlocking logic equation. Only in the last case is it necessary to
change the function assignment.
DEV01: Fct.asg.BI w/o SI cl
210 042
Fig. 3-107
DEV02: Fct.asg.BI w/o SI cl
210 092
DEV03: Fct.asg.BI w/o SI cl
210 142
DEV04: Fct.asg.BI w/o SI cl
210 192
DEV05: Fct.asg.BI w/o SI cl
210 242
DEV06: Fct.asg.BI w/o SI cl
211 042
DEV07: Fct.asg.BI w/o SI cl
211 092
DEV08: Fct.asg.BI w/o SI cl
211 142
DEV09: Fct.asg.BI w/o SI cl
211 192
DEV10: Fct.asg.BI w/o SI cl
211 242
This setting defines which output will issue the 'Close' enable to the
interlocking logic when there is 'bay interlock without substation interlock'.
Note:
The interlock conditions for bay interlock without station interlock are
included in the bay type definitions (see List of Bay Types in the Appendix).
If the interlock condition is to be modified, this is possible by modifying the
corresponding Boolean equation in the interlocking logic or by defining a
new interlocking logic equation. Only in the last case is it necessary to
change the function assignment.
