Arjo 2000 - Water Installation

27
Water installation
Water supply requirement
Water connection requirement
•
Water supply
The water supply can be arranged according to two
main alternatives:
• Water connection from floor.
(See fig. 1 & 2 on next page)
• Water connection from wall.
(See fig. 1 & 3 on next page)
Backflow prevention USA/Canada
AXXXXX1-US -Shower and Cleaning - -
ASSE1001, B64.1.1
AXXXXX2-US - Shower -ASSE1001, B64.1.1
- Cleaning ASSE1056, B64.1.2
•
Maximum static pressure 6 bar (600 kPa, 87 psi )
Minimum operating pressure (All markets) 2 bar (200 kPa, 29 psi)
Cold Water Temperature 2 - 20 °C (36 - 68 °F)
Warm Water Temperature 60 - 80 °C (140 - 176 °F)
Minimum flow / supply pipe 25 l/minute (5.5 gal/minute), per side
50 l/minute (11 gal/minute) HW + CW
Hot / Cold Water Connection 3/4 B.S.P male
Cold / Hot water 3/4” B:S:P female
Connect with shut off valves between unit and supply minimum through 16 mm
WARNING
Always assemble Bath System with the
enclosed connection hoses, which
should be without sharp bends to avoid
damage which could cause leakage.
WARNING
Always make sure that the water
supply is correctly connected to the bath
system to avoid scalding
:
• Hot water supply to hot water valve on
panel.
• Cold water supply to cold water valve on
panel.
