Arjo 2000 - Overall Dimensions - Primo

40
Overall dimensions - Primo
700
27 1/2"
5 7/8"
5 7/8"
3 1/8"
2 "
10 5/8"
22 "
15 3/4"
9 7/8"
39"/
40 1/2"
18 1/8"
2 3/4"
760
30"
150
70
460
80
3 1/8"
80
See drain illustr. below
990/ 1030
r=560
250
77 5/8" / 89 3/8"
50
600(± 100)
23 5/8" (± 4 ")
270
400
150
Possible area for location of floor drain
Wallmounted drainage
1970/ 2270
A
Equapotential bonding
120V, 60Hz
Mains supply 230V, 50Hz
2"
50
60
2 3/8"
125
4 7/8"
CW
HW
R 80
24 3/8"
620
22 5/8"
575
A
Measures inside the tub
Section A - A
Single shower 885 (34 7/8”)
Double shower 930 (36 5/8”)
Fixed height 1300 / 51 1/8")
Min. 1085/
42 3/4" (P220, 300)
Max. 1585/
62 3/8"
Fixed height 835 / 32 7/8")
Min. 620/
24 3/8" (P 220, 300)
Max. 1120/
44 1/8"
For other solutions concerning
drainage and water inlet,
please contact your Arjo
representative.
A
ll measurements are in mm unless otherwise stated.
