Technical specifications
•
Rhapsody System 20 System 23 System 25
Tub length 1600 mm (63”) 1900 mm (75”) 2150 mm (85”)
Tub + panel, length
1970 mm (77 5/8”) 2270 mm (89 3/8”) 2520 mm (99 1/4”)
Tub width 970 mm (38”) 970 mm (38”) 970 mm (38”)
Total weight 390 kg (860 lbs) 470 kg (1037 lbs) 525 kg (1158 lbs)
Water consumption (top level sensor) 195 l (51.5 gallons) 235 l (62 gallons) 280 l (74 gallons)
Filling time at 300 kPa dynamic
pressure (HW 45ºC)
(45 psi dynamic pressure (HW 113ºF))
3 minutes 30 sec 5 minutes 6 minutes
Emptying time, tub in highest position 3 minutes 4 minutes 30 sec 5 minutes 15 sec
Primo System 20 System 23
Tub length 1600 mm (63”) 1900 mm (75”)
Tub + panel, length 1970 mm (77 5/8”) 2270 mm (89 3/8”)
Tub width 760 mm (30") 760 mm (30")
Total weight 380 kg (838 lbs) 460 kg (1014 lbs)
Water consumption (top level sensor) 185 l (49 gallons) 230 l (61 gallons)
Filling time at 300 kPa dynamic pressure
(HW 45ºC)
(45 psi dynamic pressure (HW 113ºF))
3 minutes 30 sec 5 minutes
Emptying time, tub in highest position 3 minutes 4 minutes 30 sec
P220, P300
Tub rim, lowest position 620 mm (24")
Tub rim, highest position 1120 mm (44")
Stroke range 500 mm (20")
SWL ( resident + water) 500 kg (1100 lbs)
Raising time (full load) approx 30 sec
Lowering time (full load) approx 30 sec
Airborn noise
(DIN45635-19-01-KL2) max
70 dB(A)
