38
•
•
•
Primo Ferro System 23 System 25
Tub length 1870 mm (73 5/8”) 2120 mm (83 1/2”)
Tub + panel, length 2240 mm (88 1/4”) 2490 mm (98”)
Tub width 760 mm (30") 760 mm (30”)
Total weight 490 kg (1078 lbs) 545 kg (1199 lbs)
Water consumption (top level sensor) 260 l
(68.5 gallons)
290 l
(76.5 gallons)
Filling time at 300 kPa dynamic pressure
(HW 45ºC)
(45 psi dynamic pressure (HW 113ºF))
6 minutes 30 sec 7 minutes 30 sec
Emptying time, tub in highest position 5 minutes 30 sec 6 minutes 15 sec
Harmonie System 20
Tub length 1680 mm (66 1/8”)
Tub + panel, length 2050 mm (80 3/4”)
Tub width 785 mm (30 7/8")
Total weight 465 kg (1025 lbs)
Water consumption (top level sensor) 250 l (66 gallons)
Filling time at 300 kPa dynamic pressure
(HW 45ºC)
(45 psi dynamic pressure (HW 113ºF))
6 minutes 30 sec
Loads
Safe working load (SWL) (resident + water) 500 kg 1100 lbs
Max. floor loading (System 20) 2900 N/ foot pad 652 lbs / foot pad
Max. floor loading (System 23) 3250 N/ foot pad 731 lbs / foot pad
Max. floor loading (System 25) 3500 N/ foot pad 787 lbs / foot pad
Max. floor load (System 20) 54 N/cm
2
78 psi
Max. floor load (System 23) 60 N/cm
2
87 psi
Max. floor load (System 25) 65 N/cm
2
94 psi
Foot Pads
Foot pads must be bolted to the floor when rigid pipe connections are used.
