DrillSaw Highspeed 200™ User’s Guide
DFU-0225-2 Rev. 0 Page 12 of 58
2
2
.
.
5
5
.
.
3
3
AR-200C Console: Main Screen and Iconography
The console’s Main Screen (Operator display) [2] provides information about the
status of the AR-200 programs, speed, torque and coolant settings in real time.
Table 3 describes each message or button, cause and explanation when the AR-
200 is in the ready state.
Figure 3 Main Screen Overview
Table 3 Main Screen Elements
Transmission (always 1:1)
Clockwise / counterclockwise rotation
1
2
3
4
5
6
7
8
9
10
AR-200M
15.000
