DrillSaw Highspeed 200™ User’s Guide
DFU-0225-2 Rev. 0 Page 26 of 58
4.8 Pump Tubing
These instructions describe the setup of the AR-200 irrigation pump tubing.
Figure 10 Irrigation Pump Tubing Setup
Table 16 Irrigation Pump Tubing Configuration
Install the bag and spike the bag with the irrigation pump tubing
Insert the irrigation pump tubing
Close the pump arm door. It is confirmed by physically hearing
and feeling the latching mechanism. The surface of the door is
flush with the surface of the front panel.
Follow the sequences a - e when removing the irrigation tubing
The AR-200 is designed for use with physiological saline solution. Use only
suitable irrigation fluids and follow the manufacturer's medical information and
instructions.
