DrillSaw Highspeed 200™ User’s Guide
DFU-0225-2 Rev. 0 Page 17 of 58
2.5.6 AR-200SP Spray Clip
Figure 7 AR-200SP Spray Clip
Table 7 AR-200SP Spray Clip Elements
Connection for Irrigation pump tubing
The Spray Clip can be attached to the AR-200M motor with cable, and leads the
irrigation fluid to the tip of the connected burr.
The Spray Clip is not intended to be used with the motor AR-200M-ISO,
since the ISO saw attachments have their own spray rod attached.
The irrigation tubing set can be connected on the proximal side
[3] of the Spray
Clip.
The fluid pump can be activated / deactivated on the AR-200C console or with
the foot control unit S-N1.
24
25
26
