DrillSaw Highspeed 200™ User’s Guide
DFU-0225-2 Rev. 0 Page 19 of 58
3.2 Motor AR-200M
Table 11 Motor AR-200M Specifications
Diameter
26.3 mm (1.04 in.)
Length
96 mm (3.78 in.)
Weight
0.42 kg (0.93 lbs.)
Speed
300-15,000 rpm
Torque
7 Ncm
Length in Cable
3.5 m (137.8 in.)
Cleaning
Refer to Section 6.0 Cleaning and Disinfecting
Sterilization
Refer to Section 7.0 Sterilization
Mode of Operation
Non-continuous
Applied part type
Type BF
Operation Mode
30sec ON, 60sec OFF (max. 4 repetitions)
3.3 Motor AR-200M-ISO
Table 12 Motor AR-200M-ISO Specifications
Diameter
23 mm (0.91 in.)
Length
112 mm (4.41 in.)
Weight
0.38 kg (0.84 lbs.)
Speed
300-40,000 rpm
Torque
7 Ncm
Length in Cable
3.5 m (137.8 in.)
Cleaning
Refer to Section 6.0 Cleaning and Disinfecting
Sterilization
Refer to Section 7.0 Sterilization
Mode of Operation
Non-continuous
Applied part type
Type BF
Operation Mode
30 sec ON, 60 sec OFF (max. 4 repetitions)
3.4 Foot Control Unit
Table 13 Foot Control Unit (S-N1) Specifications
Width
207 mm (8.15 in.)
Height
45 mm (1.77 in.)
Depth
198 mm (7.79 in.)
Weight
1.15 kg (2.2 lbs.)
Cable length
3.5 m (137.8 in.)
Cleaning
Surface cleaning with mild detergent
Sterilization
No
Protection
IPX8, 1 m depth of immersion ,
1 hour (water-tight in accordance with IEC 60529)
