ADR141A /
ADR241A
Doc
ID
: ADR241A
_IM_01
Ref ID : ADR241A/IM/UG
Rev No. : 02
Page No.
:
102
of 1
50
Date / Time
Password protected window for “DATE / TIME” setting i.e. Set
Hour, Set Minute, Set Second, Set Date, Set Month and Set
Year.
Press the Plus / Up arrow key (+ /) to move to the next option.
Measurement
This window shows the first window of Main Menu.
8.3.3 Measurement
8.3.3.1 To View – Measurement
Measurement
This menu is to view actual load current as per CT Primary and
Secondary current selection.
Press the Right arrow key () to move to the next option.
R=0000 Y=0000
B=0000 N=0000
This window shows actual Primary load current as per the CT
Primary selection.
Press the Right arrow key () to move to the next option.
r=00.00 y=00.00
b=00.00 n=00.00
This window shows actual Secondary load current as per the
CT Secondary selection.
Press the Right arrow key () to move to the Main Menu.
Measurement
