8.3.8 Error Log
8.3.8.1 To View – Error Log
Error Log
This menu is to view “Error Log”
Press the Right arrow key () to move to the next option.
Error Code : 0000
This window will show Error Code dedicated by self
supervision function of Relay.
NOTE: The Error Code description is given in table below.
Press the Right arrow key () to return to the main menu.
Error Log
Sr. No. Error Code Description Proposed Action
1.
01 Setting Error Press LED RESET + H/W RESET
2.
02 EEPROM Error Press LED RESET + H/W RESET
3.
04 RTC Error Set Date & Time or Contact Factory
4.
04 Timer Error Set Date & Time or Contact Factory
5.
16 ADC Error Contact Factory
6.
32 FRAM Error1 Press LED RESET + H/W RESET
7.
64 FRAM Error2 Press LED RESET + H/W RESET
8.
128 TRIP_STS Error Press LED RESET + H/W RESET
8.3.9 Status
8.3.9.1 To View – Status
Status
This menu is to view “Status” i.e. Input Status, Trip Circuit
Healthy/Faulty, Software Version, Hardware Version and Relay
Serial Number
Press the Right arrow key () to move to the next option.
S1: OFF S2: OFF
S3: OFF S4: OFF
This window will show Status Input.
Press the Right arrow key () to move to the next option.
