8.2 Password
8.2.1 Editing Password and saving the settings.
To enter password in ADR141A/ ADR241A refer following steps
In ADR141A/ ADR241A all the Protection setting windows are password protected.
Procedure to enter the password is same for all windows to enter the password follow
these steps.
R=0000 Y=0000
B= 0000 N=0000 A
This window shows actual Primary load current as per the CT
Primary selection.
Press the Left arrow key () to go to the Main Menu.
Measurement
The relay will display Measurement in Main Menu.
Press the Plus / up arrow key (+ /) to move to the next option.
Relay Setting
Password protected window for “Relay Setting’’ setting i.e.
New Password, Unit ID, IP>, IP>TMS, IP>>, IE>, IE>TMS,
IE>>, IP> Curve, IE>Curve, IP> C6 Time, IE> C6 Time, IP>>
Delay, IE>> Delay, BF Delay, CT Sec, CT Pri, Test Block, Trip
Ckt., Ann Type, Ann Cont, Trip Cont, BF Cont, Com Port, Set
Parity and Baud Rate
Press the Left arrow key () to move to the next option.
Password = 000
Use Inr/Dec
Editable setting
Enter the previously set password, by using the Plus / up arrow
key (+ /) or the minus / down arrow key (- /).
Note: Default password setting is ‘000’
Press the Left arrow key () to move to the next option.
New Password = 000
Use Inr/Dec
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired New Password can be set. The
setting range is from 000 to 099.
Press the Left arrow key () to move to the next option.
