Ashida ADR141A - LED Test Procedure

Doc ID : ADR241A_IM_01
Ref ID : ADR241A/IM/TC
Rev No. : 02
Page No. : 149 of 150
ADR141A /
ADR241A
11.7 LED Test
1. Apply the auxiliary supply voltage to auxiliary supply terminals, the ON LED (green)
will be ON.
2. Enable the OC, EF instantaneous function and BF function.
3. Operate the relay by applying the current to all three phases and EF.
4. Check all the respective LED.
