Ashida ADR141A - Clear Password & Loading of Default Values

ADR141A /
ADR241A
Doc
ID
: ADR241A
_IM_01
Ref ID : ADR241A/IM/UG
Rev No. : 02
Page No.
:
99
of 1
50
Save Setting?
Mode (

)for SAVE
Now continue to press the Left arrow key () till the window
show SAVE Settings / MODE () for SAVE
Press the Left arrow key () i.e. MODE to SAVE the changes
and move to the Main Menu.
RELAY SETTING
8.2.2 Clear Password & Loading of Default Values.
There are unliking event when user forgot the password, in such case password can be
cleared by pressing following sequences
1 Press ‘HW RESET’ + ‘LED RESET + Left arrow keys () simultaneously.
2 Release ‘HW RESET’ and ‘LED RESET keys while keeping the Left arrow key
() in press condition.
Password & Fault
Memory Clear
This message will be displayed
3 Then release Left arrow key ().
Ashida Digital
OC/EF Relay
This window will flash momentarily showing the following.
Relay Type: Ashida Digital O/C EF Relay
Then the control will automatically move to next option.
ADR241A V01.05
Unit ID = 0001
This window shows Software version and the Unit ID
R=0000 Y=0000
B= 0000 N=0000 A
This window shows actual Primary load current as per the CT
Primary selection.
NOTE: This will also clear all fault memory.
