1.4 Typical Tests Information
Electromagnetic Compatibility Type Test:
Sr. No. Standard Test
I.
High Frequency
Disturbance Test
IEC60255-22-1,
IEC60255-26
(ed3): 2013
1) 2.5 kV Common Mode
2) 1 kV Differential Mode
EUT Condition Energized
II.
Electrostatic
Discharge Test-
Direct Application
IEC60255-22-2,
IEC60255-26
(ed3) : 2013
1) 8kV air discharge
2) 6kV contact discharge
Test Mode Direct and Indirect Method
EUT Condition Energized
III.
Fast Transient
Disturbance Test
IEC60255-22-4,
IEC60255-26
(ed3) : 2013
Test Voltage : ±4 KV
Repetition rate : 5 KHz and 100 KHz.
EUT Condition : Energized
IV.
Surge Immunity
Test
IEC60255-22-5,
IEC60255-26
(ed3) : 2013
Front time / time to half value : 1.2/50 µS
Source impedance : 2Ω
Common Mode : ±4 KV
Differential Mode : ±2 KV
EUT Condition : Energized
V.
Pulse Magnetic
Field Immunity
Test
IEC61000-4-9,
IEC60255-26
(ed3) : 2013
Class 5: 1000A/m field applied continuously in all
planes for the EUT
VI.
Radiated
Electromagnetic
Field Disturbance
Test
IEC60255-22-3,
IEC60255-26
(ed3) : 2013
Voltage Level
Frequency Range
Modulation
Spot Frequency
10 V/m
80 - 1000 MHz
80% AM @ 1 KHz
80, 160, 380, 450 & 900 MHz
VII.
Conducted
Disturbance
Induced By Radio
Frequency Field
IEC60255-22-6,
IEC60255-26
(ed3) : 2013
Voltage Level
Frequency Range
Modulation
EUT Condition
Spot Frequency
10 V
0.15 – 80 MHz
80% AM @ 1 KHz
Energized
27, 68 MHz
VIII.
Power Supply
Immunity Test
IEC60255-11
IEC61000-4-11
IEC61000- 4-29
IEC60255 – 26
(Ed3) : 2013
: AC voltage dip:
40%:
70%:
80%:
200 ms
500ms
5s
AC Interruption:
10ms. 20ms, 50ms, 100ms, 200ms, 0.5s and 5s
DC Voltage dip:
40% :
70% :
200ms
500ms
DC Interruption:
10ms, 20ms, 30ms, 50ms, 100ms, 200ms, 0.5s,
