Ip>050% t>0.010
Ip>>0100%
This window shows the set values of CL OC Trip, OC TMS
and OC High Fault
Press the right arrow key () to move to the next option.
IE>025% t>0.010
IE>>0100%
This window shows the set values of CL EF Trip, EF TMS and
EF High Fault.
Press the right arrow key () to move to the next option.
Ip>Normal Inv.1
IE>Normal Inv.1
This window shows the set values of CL OC Curve, and CL
EF Curve selection.
Press the right arrow key () to move to the next option.
IP> C6 Time = 01.0
IE> C6 Time = 01.0
This window shows the set values of CL OC C6 Time, and CL
EF C6 Time selection.
Press the right arrow key () to move to the next option.
IP>> Delay = 00.10
IE>> Delay = 00.10
This window shows the set values of CL OC Delay, and CL EF
Delay selection.
Press the right arrow key () to move to the next option.
Cold Load
8.3.6 TRIP TEST
TRIP TEST
Press the Right arrow key () to operate the CB.
I>>: TC:0007
I> : T
This window shows the set values of HF, IDMT Fault and Trip
Counter
Press the right arrow key () to move to the next option.
