This window will flash for a moment and it will move to the
Main Menu.
Relay Setting
8.3.4.2 To View – Relay Settings
Relay Setting
Press the right arrow key () to move to the next option.
Unit ID = 001
This window shows the set Unit ID.
Press the right arrow key () to move to the next option.
Ip>050% t>0.010
Ip>>0100%
This window shows the set values of OC Trip, OC TMS and
OC High Fault
Press the right arrow key () to move to the next option.
IE>050% t>0.010
IE>>0100%
This window shows the set values of EF Trip, EF TMS and EF
High Fault.
Press the right arrow key () to move to the next option.
Ip>Normal Inv.1
IE>Normal Inv.1
This window shows the set values of OC Curve, and EF
Curve selection.
Press the right arrow key () to move to the next option.
Ip> C6 Time = 01.0
IE> C6 Time = 01.0
This window shows the set values of OC C6 Time, and EF C6
Time selection.
Press the right arrow key () to move to the next option.
