Ashida ADR141A - Fault 1

ADR141A /
ADR241A
Doc
ID
: ADR241A
_IM_01
Ref ID : ADR241A/IM/UG
Rev No. : 02
Page No.
:
117
of 1
50
R=0000A Y=0000A
B=0000A N=0000A
This window shows the Primary values of Fault current.
Press the right arrow key () to move to the next option.
30/06/16
11:51:44.546
This window shows the Date and Time of Fault.
Press the right arrow key () to move to the main menu.
Fault 1
8.3.7 Fault 1
8.3.7.1 To View – Fault 1
Fault 1
This menu is to view “Fault 1”
Press the Right arrow key () to move to the next option.
I>>: TC:0007
I> : T
This window shows the set values of HF, IDMT Fault and Trip
Counter
Press the right arrow key () to move to the next option.
R=0000A Y=0000A
B=0000A N=0000A
This window shows the Primary values of Fault current.
Press the right arrow key () to move to the next option.
30/06/16
11:51:44.546
This window shows the Date and Time of Fault.
Press the right arrow key () to move to the main menu.
Fault 1
To View FAULT 2, FAULT 3, FAULT 4 and FAULT 5 follow the above steps
