CL IE> C6 Time = 01.0
Range 0 – 99.9S
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired CL IE> C6 Time can be set.
The setting range is from 0.00 to 99.9s in steps of 0.1s.
Press the Left arrow key () to move to the next option.
CL IP>>Delay = 00.10
Range 0 – 10.00S
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired CL IP>>Delay can be set.
The setting range is from 0.00 to 10.00s in steps of 0.10s.
Press the Left arrow key () to move to the next option.
CL IE>>Delay = 00.10
Range 0 – 10.00S
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired CL IE>>Delay can be set.
The setting range is from 0.00 to 10.00s in steps of 0.10s.
Press the Left arrow key () to move to the next option.
Save setting?
Mode (

) For Save
Press the Left arrow key () to SAVE the changes and move
to the next option.
Cold Load
This window will flash for a moment and it will move to the
Main Menu.
8.3.5.2 To View – Cold Load Settings
COLD LOAD
Press the Right arrow key () to move to the next option.
CL Enable = NO
CL Timer = 10.0S
This window shows the set Cold Load Enable function and set
CL Timer.
Press the Right arrow key () to move to the next option.
