When the given value is C1 curve, 1 is selected and when
the given value C2 curve 2 is selected.
Curve Description
C1
Normal Inverse 1 (10 Times 3.0 sec)
C2
Normal Inverse 2 (10 Times 1.3 sec)
C3
Very Inverse (10 Times 1.5 sec)
C4
Extremely Inverse (10 Times 0.8 sec)
C4A
Extremely Inverse (10 Times 0.6 sec)
C5
Long Time Inverse (10 Times 13.3 sec)
C6
Definite Time (Inst. to 99.9 sec)
Press the Left arrow key () to move to the next option.
CL IE>Curve =C1
Range C1 – C6
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired CL IE>Curve can be selected.
Seven different types of curves are provided C1 to C6.
When the given value is C1 curve, 1 is selected and when
the given value C2 curve 2 is selected.
Curve Description
C1
Normal Inverse 1 (10 Times 3.0 sec)
C2
Normal Inverse 2 (10 Times 1.3 sec)
C3
Very Inverse (10 Times 1.5 sec)
C4
Extremely Inverse (10 Times 0.8 sec)
C4A
Extremely Inverse (10 Times 0.6 sec)
C5
Long Time Inverse (10 Times 13.3 sec)
C6
Definite Time (Inst. to 99.9 sec)
Press the Left arrow key () to move to the next option.
CL IP> C6 Time = 01.0
Range 0 – 99.9S
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired CL IP> C6 Time can be set.
The setting range is from 0.00 to 99.9s in steps of 0.1s.
Press the Left arrow key () to move to the next option.
