The setting range is from 0.01 to 1.50 in steps of 0.005.
Press the Left arrow key () to move to the next option.
CL IP>> = 0100%
Range 50 – 3000%
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired CL IP>> can be set.
The setting range is from 00 / 50% to 3000% in steps of 1%.
Setting the HF value to 00 will bypass the instantaneous
element.
Press the Left arrow key () to move to the next option.
CL IE> = 025
Range 5 – 250%
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired CL IE> can be set.
The setting range is from 5% to 250% in steps of 1%.
Press the Left arrow key () to move to the next option.
CL IE> TMS = x0.010
Range X0.01 – 1.50
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired CL IE> TMS can be set.
The setting range is from 0.01 to 1.50 in steps of 0.005.
Press the Left arrow key () to move to the next option.
CL IE>> = 0100%
Range 50 – 3000%
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired CL IE>> can be set.
The setting range is from 00 / 50% to 3000% in steps of 1%.
Setting the HF value to 00 will bypass the instantaneous
element.
Press the Left arrow key () to move to the next option.
CL IP>Curve =C1
Range C1 – C6
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired CL IP>Curve can be selected.
Seven different types of curves are provided C1 to C6.
