8.3.4 Relay Settings
8.3.4.1 To Set – Relay Settings
Relay Setting
Password protected window for “Relay Setting’’ setting i.e.
New Password, Unit ID, IP>, IP>TMS, IP>>, IE>, IE>TMS,
IE>>, IP> Curve, IE>Curve, IP> C6 Time, IE> C6 Time, IP>>
Delay, IE>> Delay, BF Delay, CT Sec, CT Pri, Test Block, Trip
Ckt., Ann Type, Ann Cont, Trip Cont, BF Cont, Com Port, Set
Parity and Baud Rate
Press the Left arrow key () to move to the next option.
Password = 000
Use Inr/Dec
Editable setting
Enter the previously set password, by using the up arrow key
(+ /) or the down arrow key (- /).
Note: Default password setting is ‘000’
Press the Left arrow key () to move to the next option.
New Password = 000
Use Inr/Dec
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired New Password can be set.
The setting range is from 000 to 099 in steps of 1.
Press the Left arrow key () to move to the next option.
Unit ID = 001
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired Unit ID can be set.
The setting range is 001 to 255 in steps of 1. i.e. The unit
address will vary from 01 to 255, which means total 254
devices can be connected to single computer. The 255
address, reserved for special command. These settings are
required to communicate with the SCADA computer.
Press the Left arrow key () to move to the next option.
IP> = 050
Range 5 – 250%
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired IP> (OC Trip) can be set.
The setting range for OC Trip will be from 5% to 250% in steps
