of 1%. This setting is common to all three phases.
Press the Left arrow key () to move to the next option.
IP> TMS = x0.010
Range x0.010 to x1.50
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired IP> TMS ( OC TMS) can be set.
The setting range for IP> (OC TMS) will be from x0.01 – x1.50
in steps of x0.005. This setting is common to all three phases
Press the Left arrow key () to move to the next option.
IP>> = 0100
Range 50 – 3000%
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired IP>> (OC HF) can be set.
The setting range for OC HF will be from 00 / 50% to 3000% in
steps of 1%. Setting the HF value to 00 will bypass the
instantaneous element.
Press the Left arrow key () to move to the next option.
IE> = 025
Range 5% – 250%
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired IE> ( EF Trip) can be set.
The setting range of EF trip is from 5% to 250% in steps of 1%.
Press the Left arrow key () to move to the next option.
IE> TMS = x0.010
Range x0.010 to x1.50
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired IE> TMS (EF TMS) can be set.
The setting range for EF TMS will be from x0.01 – x1.50 in
steps of x0.005.
Press the Left arrow key () to move to the next option.
IE>> = 0100
Range 50 – 3000%
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired IE>> ( EF HF) can be set.
The setting range for EF HF will be from 00 / 50% to 3000% in
