1s and 5s
IX.
Conducted &
Radiated
frequency
Emission Test
IEC60255-25,
IEC60255-26
(ed3) : 2013
: Conducted
Frequency Range
0.15 – 0.5 MHz
0.5 – 30 MHz
EUT Condition
Limit
79 dB/µV (Quasi peak)
66 dB/µV (Average)
73 dB/µV (Quasi peak)
60 dB/µV (Average)
Energized
: Radiated
Frequency Range
30 MHz – 230 MHz
230 MHz – 1000 MHz
EUT Condition
Limits
50 dB (µV/m)
57 dB (µV/m)
Energized
Insulation Tests:
I. Dielectric Test IEC60255-27 : At 2kV 50Hz
a) between all terminals connected together and
case earth for 1 minute
b) Between independent circuits with case earth for
1 minute.
II. Impulse Voltage
Test
IEC60255-27 Test Voltage
Energy
No. of impulses
Polarity
EUT Condition
5kv, 1.2/50 µSec
0.5 J
3 on each
+ve and –ve
Non Energized
III. Insulation
Resistance
IEC60255-27
: ≥ 100MΩ @ 500V DC
Environmental tests:
I.
Cold test : IEC-60068-2-1
II. Dry heat test : IEC-60068-2-2
III.
Damp heat test, steady state : IEC-60068-2-78
IV.
Change of Temperature : IEC-60068-2-14
V. Damp heat test, cyclic : IEC-60068-2-30
VI.
Enclosure Protection Test
IP52 (with optional IP cover)
IP31 (without optional IP cover)
: IEC 60529
