ADR141A /
Ref ID : ADR241A/IM/I&P
Rev No. : 02
Page No. : 34 of 150
After fastening the relay to the Panel, mount the protective cover on the relay front panel as
shown below.
Figure 3: mounting protective cover on relay front panel.
Caution: Always use M4x25 screws for Protective Cover fitting.
After mounting the cover on relay front panel, fasten the cover fitting screw, as shown below
Figure 4: Relay mounted on the panel-front view
