3.2.6 History Fault
When the History fault selected, the following window displayed
Figure 11: History Fault
The windows/Buttons functions are as follows
Sr. No Name Description
1 Fault Buffer To view the fault buffer number
2 Read Fault To read the fault selected in the fault buffer
3 Refresh To refresh all windows and parameters
4 Clear To clear the screen
5 Save To save the fault data in history fault
6 Close To close the History fault window
