For IEC Inverse Curve
t =
K* a
I
I ref
b
–
1
For Extremely Inverse C4A Curve as per EE relays
t =
K* a
I
Iref
b
– 1
* 1.3
+ 0.22
Where
t = operation time
a = constant
I = Input current
Iref = Current threshold setting
b = Constant
K = Time multiplier setting
Curve Type Description a b
C1 Normal Inverse_1 0.14 0.02
C2 Normal Inverse_2 0.06 0.02
C3 Very Inverse 13.5 1
C4 Extremely inverse 80 2
C4A
Extremely Inverse
(C4A) as per EE Relays
80 2.2
C5 Long Time Inverse 120 1
C6 Define Time - -
