ADR141A /
Doc ID : ADR241A_IM_01
Ref ID : ADR241A/IM/MS
Rev No. : 02
Page No. : 72 of 150
5 MEASUREMENT SHEET
5.1 Measurement
Measurement window displays the primary and secondary values of phase and ground
current based on the power system network.
Parameter Unit Description
R = 0000 A Primary current in phase R
Y = 0000 A Primary current in phase Y
B = 0000 A Primary current in phase B
N = 0000 A Primary current in Neutral CT
r = 00.00 A Secondary current in phase R
y = 00.00 A Secondary current in phase Y
b = 00.00 A Secondary current in phase B
n = 00.00 A Secondary current in Neutral CT
