ADR141A /
Ref ID : ADR241A/IM/SS
Rev No. : 02
Page No. : 77 of 150
This setting is used to set the time-delay for Definite Time (C6) setting if selected for first stage ground
over current.
14.
IP>> Delay 0.05s 000 – 10.0s in steps of 0.01s
This setting is used to set the time-delay for second stage over current.
15.
IE>> Delay 0.05s 000 – 10.0s in steps of 0.01s
This setting is used to set the time-delay for second stage ground over current.
16.
BF Delay 50ms 000 – 800 msec.
This setting for the time-delay for the CBF trip.
17.
CT Secondary 1 A 1 A/5 A
This setting is used to set the CT Secondary
18.
CT Primary 10 A 10 – 5000A in step of 1A
This setting is used to set the CT Primary.
19.
Test Block No
01 – 02 (1= Yes, 2= No)
This setting is used to enable (turn on) or disable (turn off) the CB Trip operation through relay HMI.
20.
Trip Circuit No 01 – 02 (1= Yes, 2= No)
This setting is used to enable (turn on) or disable (turn off) Trip circuit supervision. This is used to
monitor trip coil which is used to trip the circuit breaker.
21.
Ann. Type 1 1 – 4
This setting is used select the annunciation type.
22.
Ann. Contact 1 01 –02 (1=SR, 2=HR)
This setting specifies to ann. contact can be set to Manual/Hand reset (HR) or Self reset (SR)
23.
Trip Contact 1 01 –02 (1=SR, 2=HR)
This setting specifies to Trip1 and Trip2 contact can be set to Manual/Hand reset (HR) or Self reset (SR)
24.
BF Contact 1 01 –02 (1=SR, 2=HR)
This setting specifies to BF contact can be set to Manual/Hand reset (HR) or Self reset (SR)
25.
Com Port USB USB/RS485
This setting specifies to select communication port for 103 communications.
26.
Set Parity None None/ Even/ Odd
This setting is used to set parity. It is important that both relay and master station are set with the same
parity setting.
27.
Baud Rate 57600 2400/ 4800/ 9600/ 14400/ 19200/ 28800/
38400/ 57600
This setting is used to set Baud rate It is important that both relay and master station are set with the
same Baud rate setting.
