ADR141A /
Ref ID : ADR241A/IM/SS
Rev No. : 02
Page No. : 79 of 150
This setting is used to set the time-delay for the Definite Time (DT) setting if selected for first stage
Ground over current (Measured) element.
14.
CL IP>> Delay 0.10s
0.00 – 10.0s in steps of 0.01s
This setting for the time-delay for the definite time setting if selected for second stage over current
element.
15.
CL IE>> Delay 0.10s
0.00 – 10.0s in steps of 0.01s
This setting for the time-delay for the definite time setting if selected for second stage ground over current
element
6.3 Date and Time setting
Sr. No Parameter Defaults setting Settings / Ranges
1.
SET Hours 00
00
–
23 Hrs in step 1.
Hour setting needed when relay is not connected to SCADA system
2.
SET Minutes 00
00
–
59 Mins in step 1.
Minutes setting needed when relay is not connected to SCADA system
3.
SET Seconds 00
00
–
59 Sec. in step 1.
Seconds setting needed when relay is not connected to SCADA system
4.
SET Date 01
01
–
31 Days in step of 1.
Date needed when relay is not connected to SCADA system
5.
SET Month 01
01
–
12 Months in step of 1.
Month needed when relay is not connected to SCADA system
6.
SET Year 01
00
–
99 Years in step of 1.
Year needed when relay is not connected to SCADA system
