Doc ID : ADR241A_IM_01
Ref ID : ADR241A/IM/CS
Rev No. : 02
Page No. : 89 of 150
ADR141A /
7.10 Configuration
To configure the IED for this protocol, please see the Configuration chapter.
7.11 IEC-103 Protocol Mapping
Sr. No. INF Description GI TYP COT FUN
1
Semantics of INFORMATION NUMBER : System Functions in monitor direction
0 End of general interrogation - 8 10 255
0 Time synchronization - 6 8 255
2 Reset FCB - 5 3 160
3 Reset CU - 5 4 160
4 Start/Restart - 5 5 160
5 Power on - 5 6 160
Sr. No. INF Description GI TYP COT FUN
2 Semantics of INFORMATION NUMBER : Status indications in monitor direction
18 Protection active
X
1
1,7,9,11,12,20,21
160
19 LED Reset
-
1
1,7,11
160
145 Relay Error
X
1
1,7,9,11,12,20,21
127
21
Test
X
1
9,11
127
22
Local Parameter setting
X
1
9,11
160
27
Auxiliary Status 1
X
1
1,7,9,11
160
28
Auxiliary Status 2
X
1
1,7,9,11
160
29 Auxiliary Status 3
X
1
1,7,9,11
160
30 Auxiliary Status 4
X
1
1,7,9,11
160
64
Start/ Pick-up L
1
X
2
1,7,9
160
65
Start/ Pick-up
L
2
X
2
1,7,9
160
66
Start/ Pick-up L
3
X
2
1,7,9
160
84
General Start/ Pick-up
X
2
1,7,9
160
117
Ip> PKP
X
2
1,7
126
103 Ip>> PKP
X
2
1,7
126
68 General Trip
-
2
1,7
160
69
Trip L
1
X
2
1,7
160
70
Trip
L
2
X
2
1,7
160
71
Trip L
3
X
2
1,7
160
85
Breaker failure
-
2
1,7
160
90 Trip Ip>
X
2
1,7
160
91
Trip Ip>>
X
2
1,7
160
To Next Page
