Ashida ADR141A - Page 91

Doc ID : ADR241A_IM_01
Ref ID : ADR241A/IM/CS
Rev No. : 02
Page No. : 91 of 150
ADR141A /
ADR241A
Sr. No. INF Description TYP COT FUN
7 Semantics of INFORMATION NUMBER : Private Frames in monitor direction
0 Fault List Request 24 31 160
1 Fault Data Request 245 11 127
Sr. No. INF Description TYP COT FUN
8 Semantics of INFORMATION NUMBER : System Function in control direction
0 Initialization of general interrogation 7 9 255
0 Time synchronization 6 8 255
Sr. No. INF Description COM* TYP COT FUN
9 Semantics of INFORMATION NUMBER : General Command in control direction
19 LED Reset ON 20 20 160
124 Trip ON 20 20 127
* Permissible selections of DCO values are specified in COM column (Ref. IEC60870-5-103
Section7.2.6.4)
