→ General Settings ←
-
-
-
When the Password is set, press the LED Reset Key it will
come out of curser ( ⌃ ).
Press the left arrow key () the relay will display as follow.
Note:
• Default password setting is ‘0000’
• The set Password will remain common for all the
settings
Save Settings?
Mode for Save
Now again press the left arrow key () the ÓK’ window will
appear for a moment and the control will automatically return
to ‘’General Settin
g
s’
OK
This window will flash for moment
The control will return to the main menu
Password = 0000
New Password ⌃
To Change Password (New Password)
Press the LED Reset Key this will display the curser ( ⌃ )
below the password digits at Extreme Right ( 0000 ) this
curser ( ⌃ ) can be shifted right to left and left to right using
the left arrow key () and Right Arrow key ().
By using the up arrow key ( + / ) or the down arrow key ( - /
) a given value can be set for each of the digits. The range
is from 0 to F. (The range is from 0000 – FFFF)
When the desired Password is set press the LED Reset/EDIT
Key it will come out of curser ( ⌃ ).
Press the left arrow key () the relay will display other
windows one by one till the following window.
