8.3.13 DATE TIME SETTINGS
8.3.13.1 To Set – Date Time Setting
Date/Time
Password protected menu to set the Date and Time.
Press the left arrow key () the relay will display as follows.
Password = 001
Use INR/DEC
Enter the previously set password, by using the up arrow key
( + / ) or the down arrow key ( - / ). As per the Enter the
Password selection.
Press the left arrow key () the relay will display as follows.
SET Hrs = 017
Range 0 – 23
By using the up arrow key ( +
) or the down arrow key
( - /) Hours can be set. The setting range is from 0-23 in
steps of 1.
Press the left arrow key () the relay will display as follows.
SET Mins = 017
Range 0 – 59
By using the up arrow key ( +
) or the down arrow key
( - /) Minutes can be set. The setting range is from 0-59 in
steps of 1.
Press the left arrow key () the relay will display as follows.
SET Sec = 017
Range 0 – 59
By using the up arrow key ( +
) or the down arrow key
( - /) Seconds can be set. The setting range is from 0-59 in
steps of 1.
Press the left arrow key () the relay will display as follows.
SET Date = 017
Range 1 – 31
By using the up arrow key (+
) or the down arrow key
( - /) Date can be set. The setting range is from 1-31 in steps
of 1.
Press the left arrow key () the relay will display as follows.
SET Month = 004
Range 1 – 12
By using the up arrow key (+
) or the down arrow key
( - /) Month can be set. The setting range is from 1-12 in
steps of 1.
Press the left arrow key () the relay will display as follows.
