NUMERICAL OC/EF PROTECTION RELAY ADR141C/241C
ASHIDA Electronics Pvt. Ltd.
Ref: Manual / ADR141C / 241C
Issue: 04D
Date : 10.07.2014
Page 49/86
8.3.7.3 To View
Relay/ LED Config. Setting
Relay/ LED Config.
Press the right arrow key () the relay will display as
follows.
Loading Factory
Settings : NO
This window will show Loading Factory Setting done
previously.
Press the right arrow key () the relay will display as
follows.
RL1 A = 01FF
RL1 B = 0000
This window will show Relay config. setting done
previously.
Press the right arrow key () the relay will display as
follows.
L1 Green A = 0000
L1 Green B = 0000
This window will show Relay config. setting done
previously.
Press the right arrow key () the relay will display as
follows.
RL2 A = 01FF
RL2 B = 0000
This window will show Relay config. setting done
previously.
Press the right arrow key () the relay will display as
follows.
RL3 A = 01FF
RL3 B = 0000
This window will show Relay config. setting done
previously.
Press the right arrow key () the relay will display as
follows.
RL4 A = 0088
RL4 B = 0000
This window will show Relay config. setting done
previously.
Press the right arrow key () the relay will display as
follows.
L1 Red A = 8000
L1 Red B = 01FF
This window will show Relay config. setting done
previously.
Press the right arrow key () the relay will display as
follows.
