8.2.2 Clear Password
There are unlinking event when user forgets the password, in such case password can be
cleared by pressing following sequences.
1) Press ‘HW RESET’ + ‘LED RESET/EDIT’ and LEFT ARROW KEY () this will initialize
relay hardware.
2) Release ‘HW RESET’ + ‘LED RESET/EDIT’ and keeping the left arrow key () pressed
till the following message is display. This will Reset password to ‘0’ (Zero).
Ashida Digital
OC/EF Relay
Fault Memories &
Password clear
R= 0000 Y = 0000
B = 0000A
ADR141C – 01.20
Unit ID = 0001
R= 0000 Y = 0000
B = 0000A
This is default window showing the actual Primary Load
Current as per “CT Sec” selection
