NUMERICAL OC/EF PROTECTION RELAY ADR141C/241C
ASHIDA Electronics Pvt. Ltd.
Ref: Manual / ADR141C / 241C
Issue: 04D
Date : 10.07.2014
Page 51/86
8.3.8 TRIP TEST
8.3.8.1 To View Trip
Test
Fault 1
Trip Test
This function is used for Tripping purpose.
Press the right arrow key () the relay will display as follows.
I>>:
I>: T
This window will show Trip flag.
Press the right arrow key () the relay will display as follows.
R=0000 Y=0000
B=0000A
This window will show primary fault current in R Y B.
Press the right arrow key () the relay will display as follows.
3Io=0000A
Trip Count: 0000
This window will show primary fault current of 3Io and Trip
count.
Press the right arrow key () the relay will display as follows.
20/06/13
16:45:50:603
This window will show date and time of fault.
Press the right arrow key () the relay will display main
menu i.e. Fault 1.
