7.2 Type Test Details
Sr. No. Title Standard no.
Electromagnetic Compatibility Type Test:
1. High Frequency Test : IEC 60255-22-1, class – III
: Frequency : 1MHz Damped Oscillatory
: Longitudinal :5 KV (peak)
: Duration: sec duration 2 sec.
: Between input current Terminal
2. Electrostatic Discharge
Direct Application
: IEC 60255-22-2 Class III and IEC 61000-4-2 class III.
: Contact discharge: 6kV,
: Air discharge: 8KV
: Polarity: both +ve and –Ve polarities.
3. Indirect Application : IEC-61000-4-2, Class-III
4.
Fast Transient
Disturbance
: IEC 60255-22-4 and IEC 61000-4-4, class A
: 1.2KV; 5/50ns; 5KHz burst duration = 15ms.
:
Repetition rate 300ms; Both polarities; Ri = 50Ω; duration 1 min.
5. Surge Immunity Test
: IEC 60255-22-5 / IEC 61000-4-6 class 4
: Differential Mode = 2kV
: Common Mode = 4kV
: 1.2/50uS , 5 surges of each polarity
6. Power Frequency
Magnetic Field Test
: IEC-61000-4-8, Class-V
7. Radiated
Electromagnetic Field
Disturbance
: IEC- 60255-22-3
: EN-61000-4-3
: Frequency 80MHz – 1GHz
8. Conducted Disturbance
Induced By Radio
Frequency Field
: IEC 60255-22-6 / IEC 61000-4-6: 1996.
: Freq. 150kHz – 80MHz, Amplitude 10 V, Modulation 80% AM
@ 1 KHz
9. AC Ripple In DC
Supply Test
: IEC 60255-11
10. Radiated Emission : IEC 60255-25
Insulation Tests:
11.
High Voltage Test
: IEC 60255-5. class – III
: At 2.5kV 50Hz between all terminal connected together and
earth for 1 minutes
12.
Impulse Voltage Test : IEC 60255-5. class – III
: Test voltage: 5KV (peak) 1.2 / 50us,
: Energy :0.5 J,
: Polarity : + ve and – Ve
: Nos. of impulses : 3 positive and 3 negative impulse
: Duration between Impulses : 5 sec.
