8.3.12 STATUS
8.3.12.1 To View – Status
CB NO: OFF
CB NC: OFF
This window will show status of Digital Input i.e. CB NO and
CB NC
Press the right arrow key () the relay will display as follows.
Status
Status
This menu is to view the Status of Digital Input, Trip Circuit
Supervision, circuit breaker and H/W / S/W version.
Press the right arrow key () the relay will display as follows.
Trip Ckt: Healthy
Ckt Brker:?
This window will show status of Trip ckt. and ckt. Breaker.
Press the right arrow key () the relay will display as follows.
S/W V: 01.20
H/W V: 01.01
This window will shows the software and hardware version of
relay
Press the right arrow key () the relay will display the main
menu.
