8.3.4.2 To View – General Setting
General Setting
General Setting
Press the right arrow key () the relay will display as
follows.
Test Block = NO
Trip Ckt. = NO
This window will show General Setting done previously.
Press the right arrow key () the relay will display as follows.
Unit ID = 001
This window will show General Setting done previously.
Press the right arrow key () the relay will display as follows.
CT Sec. = 1Amp
CT Primary = 0100A
This window will show General Setting done previously.
Press the right arrow key () the relay will display as follows.
BF Enable = No
BF Delay = 200
This window will show General Setting done previously.
Press the right arrow key () the relay will display as follows.
Frequency = 50Hz
This window will show General Setting done previously.
Press the right arrow key () the relay will display Main
Menu.
Baud Rate = 57600
This window will show General Setting done previously.
Press the right arrow key () the relay will display as follows.
( Only for ADR241C )
