NUMERICAL OC/EF PROTECTION RELAY ADR141C/241C
ASHIDA Electronics Pvt. Ltd.
Ref: Manual / ADR141C / 241C
Issue: 04D
Date : 10.07.2014
Page 30/86
General Setting
Save Setting?
Mode For Save
To Save any changes.
Press the left arrow key () the relay will save the changes
and the following message is display.
Note: If changes made are not to be saved press LED
Reset or leave key pad untouched for 100 sec.
Frequency = 50Hz
Range 50 – 60Hz
By using the up arrow key ( +
/
 ) or the down arrow key
( - /) the desired Frequency can be selected.. i.e. 50Hz or
60Hz.
Press the left arrow key () the relay will display as follows.
OK
This window will flash for moment
The control will return to the main menu
